LUX Solar Red and Black Battery Cable with Inline Fuse holder and Solar Fuse

LUX Solar Battery Cables with Inline Fuse

Regular price
$39.99 NZD
Sale price
$39.99 NZD
Regular price
Sold out
Unit price

This LUX Solar 6 mm2 battery cable is terminated with IP67 MC4 connectors and is specifically designed to be compatible with all LUX Solar charge controllers and small victron controllers (75/10,75/15 100/20)

We can also make it to length to suit any charge controller of 20 amps or below

The cable includes an IP68 inline fuse holder and Bussmann solar fuse to protect your cables, charge controller and batteries from damage. The cables come ready to connect directly to your battery with low galvanic corrosion ring terminals.

All of our cables and connectors are tested and certified to international standards by the German inspector TUV.

International certifications for the MC4 connectors include

UL6703, EN50521:2008, IEC61215, IEC61730, IEC61646

Cable tested to international standard EN50618:2014

Dimensions 6 mm2
Degree of protection IP67/IP68
Cable resistance 3.3 mΩ/metre
Contact Resistance  ≦ 5 mΩ
Rated Voltage DC 1000 V (TUV)
Contact Tin plated red copper


If you would like to know the correct cables to use for your marine  or caravan solar system please contact us, or read through our cable knowledge article.
