Fuses, Circuit breakers and Circuit Protection

Fuses, circuit breakers, isolators and surge protection for 12, 24 and 48 V solar and battery systems. A fuse protects the cable, not the appliance, so size the cable first and fuse below what it can carry. Check the voltage rating too: 32 V fuses suit 12 and 24 V systems, 48 V banks need 58 V or higher, and PV strings need a DC rating above the array's open-circuit voltage.

In brief: PV fuses or an MC4 inline holder on the panel side, a solar circuit breaker to isolate the array, a Class T fuse at the battery terminal (the standard for lithium banks), MEGA or ANL fuses on main DC feeds and MIDI fuses on branch circuits. See our cables guide, or email technical@luxsolar.co.nz before you order.
