Any-Gridâ„¢ Hybrid Inverter Charger (by German solar technology companyÂ PHOCOS)

The Phocos Any-Grid^TMÂ PSW-H Inverter Charger Series (Pure Sine Wave Hybrid) represents Phocosâ€™ most versatile line of inverters/chargers. Flexibility and reliability are key characteristics of this product line, with a strong potential for cost saving opportunities in real world conditions. The Any-Grid PSW-H converts DC (Direct Current) energy into AC (Alternating Current), with multiple advantages beyond standard inverters. This product includes an integrated MPPT charge controller and can function as an AC to DC battery charger, which provides flexible energy access solutions in a broad range of applications.

The battery can be charged from solar and/or an AC source (public grid or generator), with easily programmable priorities. The Any-Grid PSW-H can function without an AC source or alternatively even without solar, as a pure uninterruptible power supply (UPS). When the utility grid or AC generator fails, the Any-Grid PSW-H immediately switches to â€˜Off-Gridâ€™ mode within 10 ms (typical, in UPS mode) to securely power the loads at all times. Solar can be set as the priority energy source to save electricity costs.Â

The Any-Grid PSW-H can function in a battery-free mode. In this mode, for installations with stable public grids, grid energy consumption can be reduced without the need to invest in a costly battery bank. Additionally, power can be supplied directly to loads from the grid and solar simultaneously.

This unit comes with a quality, integrated MPPT charge controller. The controller accepts particularly high PV voltages, allowing many PV modules to be connected in series, decreasing installation cost and avoiding combiner boxes. Up to 9 inverters can be connected parallel, 3-phase or split-phase for up to 45 kW of synchronized AC power

Product Features

Flexible, advanced features with options to solve many common challenges in the field
Integrated high-voltage MPPT charge controller. The high-voltage PV connection means in most scenarios the PV modules can simply be connected in series, avoiding costly combiner boxes and string fuses or diodes, thus reducing total system cost
Integrated AC battery charger
Charge controller functions even if inverter is turned off to keep batteries fully charged
Compatible with Lithium batteries
Functions without an expensive battery to reduce energy consumption from the grid with minimal investment
Detachable display / communication unit with 6 LEDs and an intuitive LCD screen
High level of connectivity: BLE, USB-OTG (on-the-go), RS-485, RS-232, relay for generator start
Datalogger with up to 60 days of data storage
Store or load parameters via USB for quick configuration
Integrated buzzer for error indications
Galvanic isolation of battery allows positive or negative grounding
Up to 9 inverters can be connected in parallel or 3-phase for up to 45 kW of synchronized AC power
Removable filter reduces dust buildup in the inverter

For more info, see: https://www.phocos.com/product/psw-h-3-kw-5-kw/
