MC4-Evo STAUBLI IP68

The original MC4-Evo 2 guarantees high performance even in harsh environment.

Internationally certified with IEC, UL, JET, cTÜVus. Approved for DC 1500 V (IEC, JET), DC 1500 V (UL) unrestricted access. MULTILAM Technology, has proven the quality and durability several 100 million times since 2004. Suited for all climatic environments due to UV resistance, ammonia and high IP class (IP68). Mating compatibility with MC4 connector family.

Features:

• Internationally certified with IEC, UL, JET, cTÜVus.
• Approved for 1500 V DC (IEC, JET, UL) unrestricted access
• MULTILAM Technology
• Suited for all climatic environments
• Resistance to UV, ammonia, and high IP class (IP68).
• Mating compatibility with Original MC4 connector family.

Specifications

• 1500V
• 45 A (4.0 mm² / 12 AWG)
• 53 A (6.0 mm² / 10 AWG)
• Cable OD: 4.7-6.4mm
• Conductor Size: 4-6mm²
• IP68

Certification

• IEC 62852
• UL 6703

Approvals

• TÜV
• UR
• JET
