Victron Multi RS19 Solar 19" Rack Mountable
Victron Multi RS19 Solar 19" Rack Mountable
SKU: Multi RS19 Solar 48/6000/100-450/100 230V | PMR482602030
Couldn't load pickup availability
Shipping $ & Timeframe
Shipping $ & Timeframe
Free Shipping New Zealand wide.
Orders are shipped Mondays to Fridays and take 1-3 working days to arrive. Orders received before midday ship out same-day.
Warranty & Returns
Warranty & Returns
5 Year Warranty
We have a 7 day change of mind return policy, subject to a restocking fee.
Datasheets, Manuals, Certifications
Datasheets, Manuals, Certifications
The Victron Multi RS19 Solar 48/6000/100-450/100 230V is a lightweight, high-frequency 6 kVA inverter/charger with two 450 V solar trackers built in, for up to 6 kW of solar on a 48 V battery bank. It's the 19" rack-mount version of the Multi RS Solar, and runs quietly and efficiently with low standby power.
Free NZ shipping on Victron inverter/chargers.
Please note: the Multi RS19 Solar is not recommended for marine or coastal installations.
Key features
- Built-in 450 V dual solar trackers: two independent trackers at 65 to 450 V, 3 kW each, give you 6 kW of solar without a separate charge controller. Add more later with extra solar chargers or PV inverters on the AC output.
- Made for 19" battery racks: fits a standard 19" rack next to rack-mount 48 V batteries for a compact installation, with a BMS-Can port to connect to them
- 6 kVA with strong surge power: 4800 to 5300 W continuous at 25 °C depending on battery voltage, and 9 kW peak for 3 seconds to handle start-up surges
- Backup, off-grid and generator modes: switches to battery power during a grid outage, runs with no grid connection at all, or controls a generator to keep its run-hours down
- PowerControl & PowerAssist: set a maximum grid or generator current and the Multi RS reduces charging to stay under it, then adds battery power when loads peak
- Up to 100 A battery charging: 88 A from grid or generator, and up to 100 A combined with solar, with a battery temperature sensor included
- Two AC outputs: a second output for non-critical loads runs straight from the AC input, so those loads don't drain the battery during an outage
- Display, Bluetooth and remote monitoring: see every reading on the built-in display or in the VictronConnect app, with trend history. Connect a GX device such as the Cerbo GX for system monitoring, data logging and remote firmware updates.
Specifications
| Continuous output power | 4800 to 5300 W @ 25 °C (46 to 52 V DC), 4500 W @ 40 °C, 3000 W @ 65 °C |
| Peak power | 9 kW for 3 seconds, 7 kW for 4 minutes |
| Output | 230 VAC ± 2%, 50 Hz |
| Efficiency | 96.5% at 1 kW, 94% at 5 kW |
| Zero load power consumption | 20 W |
| Solar input | 2 trackers, 65 to 450 V (450 V max open circuit), 3 kW each, 6 kW total |
| Maximum charge current | 88 A from AC, 100 A total (AC + solar) |
| Transfer switch | 50 A |
| DC input voltage range | 38 to 62 V |
| Three-phase and parallel | Three-phase with one unit per phase. Parallel not supported. |
| Protection category | IP20 |
| Dimensions (H × W × D) | 133 × 483 × 430 mm |
| Weight | 12.2 kg |
Full specifications are in Victron's Multi RS19 Solar datasheet (PDF).
This unit is supplied after a chat with our technical team, so we can make sure it suits your system. Email technical@luxsolar.co.nz to get started.
