475 Watt Mono Solar Panel - Half Cut LONGi HPBC - 180 x 113.4 cm

475 Watt Mono Solar Panel - Half Cut LONGi HPBC - 180 x 113.4 cm

SKU: LR7-54HVH-475M

Regular price $299.99 NZD
Regular price $299.99 NZD Sale price $299.99 NZD
Sale Sold out
Taxes included. Shipping calculated at checkout.
Model
Quantity

Shipping

This item is very large and fragile. Shipping from $69.99 (North Island) to $94.99 (South Island). and pickupDiscount

Orders are shipped Mondays to Fridays and take on average 1-3 working days to arrive.

Warranty & Returns

We have a 7 day change of mind return policy, subject to a restocking fee.

LONGi 475W HPBC Cell — Black Frame

FREE pick up from Panmure, Auckland. Delivery from $69.99+ depending on location.

This is the most powerful fixed panel in our range — 475 watts from LONGi's latest HPBC cells in a sleek, all-black frame. If you're filling a roof and want maximum output from minimum space (fewer panels, less wiring, less mounting), this is the one to reach for. Great for off-grid baches, tiny homes, larger caravan and motorhome roofs, and grid-tie top-ups right across the North and South Island.

LONGi's new-generation HPBC cell technology opens a new chapter in high-efficiency cells. Cell efficiency exceeds 25.0%, with module efficiency of 23.3% — so you get more watts per square metre than older PERC panels of the same physical size.

Not sure how many panels you need? Size your system in a few minutes with AnyKit™.

Prefer a dual-glass panel? We also stock the 475 Watt LONGi bifacial version of this panel.

Specifications – 475 W Panel Model

  • Maximum Power (Pmax): 475 W
  • Module Efficiency: 23.3%
  • Dimensions: 1800 × 1134 × 30 mm
  • Open Circuit Voltage (Voc): 40.18 V
  • Short Circuit Current (Isc): 15.03 A
  • Voltage at Maximum Power (Vmp): 33.16 V
  • Current at Maximum Power (Imp): 14.33 A
  • Cell Type: LONGi HPBC mono half-cut

Complete your installation

Everything you need to get this panel on the roof and wired in:

Want it all matched and pre-wired? Build a complete plug-and-play system with AnyKit™ and we'll size the panel, controller, cable and mounts for you.

HPBC

HPBC (Hybrid Passivated Back Contact) solar cells, are the latest solar technology that introduces unobstructed front shading by metal contacts. This pioneering approach optimizes photon collection, resulting in enhanced conversion efficiency. The HPBC cell sets a new industry standard, significantly enhancing light absorption and photovoltaic conversion capability, resulting in substantially improved module power output.

The result is panels capable of generating more energy under higher temperatures and lower light. Some studies have shown that that HPBC cells can produce output up to 10% higher under the same conditions as PERC products.

Monocrystalline

At LUX Solar we only source monocrystalline panels as they offer the highest efficiency. Monocrystalline panels are manufactured from a single rod of silicon thus the crystal structure inside the silicon is uniform, with very few impurities. Polycrystalline panels on the other hand are made up of smaller crystal structures that introduce grain boundaries in each solar cell. This causes inefficiencies in the conduction of electrons due to defects associated with the crystal boundary.

LONGi

LONGi is a leading manufacturer of high-performance solar panels, with a strong market position and a global presence in over 30 countries. LONGi Solar is recognized as a top-tier solar panel manufacturer, and is considered a reliable and high-quality supplier of solar panels. The term "Tier 1" is used in the solar industry to refer to solar panel manufacturers that are vertically integrated, meaning they produce the majority of their own solar cells and have control over their supply chain.
