Victron Lynx Power In

The tidy, modular way to wire your battery bank. The Lynx Power In is a modular DC busbar, used to connect batteries to the Lynx DC distribution system. It gives you a clean, bolt-together backbone for your 12 V, 24 V or 48 V DC system — no messy tangle of ring terminals stacked on a single stud.

The Lynx Power In contains a positive and negative busbar with 4 connections for batteries, loads, or chargers, and a ground connection.

Key features

• Modular DC busbar — the foundation of a tidy, expandable Lynx DC distribution system
• Positive and negative busbars with 4 connections for batteries, loads or chargers, plus a ground connection
• Bolts directly to other Lynx modules (Distributor, Shunt VE.Can, Smart BMS) — build up your distribution system without extra cabling between modules
• M10 connection studs
• Rated up to 1000 A continuous — suitable for 12 V, 24 V and 48 V systems
• Covered by Victron's standard 5-year warranty

Part of the Lynx Distribution System

It is part of the Lynx Distribution system, a modular busbar system that incorporates DC connections, distribution, fusing, battery monitoring, and/or lithium battery management. For more information also see the DC Distribution Systems product page.

The Lynx Distribution System consists of the following parts, which all bolt together:

• Lynx Power In (this product) — a positive and negative busbar with 4 connections for batteries or DC equipment.
• Lynx Distributor — a positive and negative busbar with 4 fused connections for batteries or DC equipment together with fuse monitoring.
• Lynx Shunt VE.Can — a positive busbar with a space for a main system fuse and a negative busbar with a shunt for battery monitoring. It has VE.Can communication for monitoring and setup with a GX device.
• Lynx Smart BMS — for use together with Victron Energy Smart Lithium batteries. It contains a positive busbar with a contactor that is driven by a battery management system (BMS) and a negative busbar with a shunt for battery monitoring. It has Bluetooth communication for monitoring and setup via the VictronConnect App and VE.Can communication for monitoring with a GX device and the VRM portal.

The images in this listing show several Lynx modules so you can see how the system fits together. This product is the Lynx Power In busbar only — the Distributor, Shunt VE.Can and Smart BMS are sold separately.

Complete your DC distribution setup

• Lynx Class-T Power In — add fused input protection for your lithium battery strings.
• Fuses & circuit protection — the right fuse or breaker to keep your battery connections safe.
• Batteries — the lithium (LiFePO4) and AGM banks your Lynx system connects together.

Not sure how to spec your DC distribution? Build a matched system in minutes with AnyKit™, or email technical@luxsolar.co.nz and we'll point you to the right parts.
